Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 171
Fig. 8. … Fig. 9.Figs. 6 to 9.—Splicing Manilla rope. whipped with a small piece of twine. The half of the strand 7 is nowlaid in three turns, and the half of 8 also laid in three turns. Thehalf strands now meet and are tied in a simple knot, 11, Fig. 8,making the rope at this point its original size. The…
Machine design
