bo1-4 1) o e a ^ei^ in that the roller is mounted upon a slide which movesradially with the cam disk. The cam is here requiredto move the roller the distance oB while turningthrough the angle BC. The throw circle o, 6, 12 isdrawn with a diameter equal to the radial movementof the roller and is…
