Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 436
be considered. Table lo for the discharge capacity of safety valves was computed C = total weight or volume of fuel of any kind burned perhour at time of maximum forcing, lbs. or cu. ft., H = the heat of combustion, B.t.u. per lb. or cu. ft. of fuelused, £> = diameter of valve seat, ins., X =… … Traced downward from the maximum pitch to the curve for the diameter of the rivets and then to the left where read the per-centage of plate strength.Fig. 24.—Percentage of plate strength of boUer joints. Lloyds
