Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 453
Card 4. Speed 301 R.P.M, Valve Travel1.98 Ins. … Card 5. Speed 303 R.P.M. Valve Travel2.37 Ins. Fig. 16.—Effect of small port openings on indicator cards. gage in the steam chest, it was placed in the steam pipe 20 ft. fromthe engine. The gage had been recently tested. No doubt the pres-sure in the chest was somewhat below that shown by the gage,…
Machine design
