A HANDBOOK OF WEAVES 342 and figure are each drafted with the respective weave as if that weave covered the whole draft. The opera- tions of drafting are as follows : 1. The face warp threads are filled in throughout FIG. 1670. FIG. 1671. … FIG. 1673. FIG. 1672. the entire draft with the required weave on the face picks. Risers are then inserted to bring the back warp threads to conform to the figure of the motif. Fig. 1674 is the motif. Fig. 1675 shows a plain weave (dotted squares) on the face warp and face filling, the back warp…
