r sheets,forming what are known as detail drawings. In verycomplex work hundreds of these drawings are oftennecessary in order that the designer or draftsman maymake certain that every part of the construction willwork out properly and that the workmen will understandhis intentions, and in many… … A COBNEB OF THE AUTHOBs HOME WORKEOOM.(For Working Drawings of the Table and Bench see Figs. 147 and ISO, Chapter VI.) WORKING-DRAWINGS 87 portions which cannot be covered by notes upon thedrawings. The average person usually has difficulty in reading aworking-drawing, for the fact that he looks at…
