Ji^*% … Fig-. 44. Automatic Steam Transfer for Timber, Lumber aud Slabs. The boards are carried along- by tlie cylinders, C C C, until they hit the bumper, B. This movement admits steam to the cylinder, CY, which raises the revolving- chains or skids, which transfers the stock sidewise to other live…
