Fig-. 44. Automatic Steam Transfer for Timber, Lumber aud Slabs. The boards are carried along- by tlie cylinders, C C C, until they hit the bumper, B. This movement admits steam to the cylinder, CY, which raises the revolving- chains or skids, which transfers the stock sidewise to other live… … Fiy. 45. Automatic Gang Luinber-Tiimmer. It may be set to cut autoiiiaticallyto any desired length.
Woodwork
