ations, 176 HAWKINS ELECTRICITY as with the single loop armature, the latter must be replacedby one having a great number of loops properly connectedto commutator segments and so arranged that the successiveloops begin the cycle progressively. The difficulties encountered in connecting up… … Fig. 184.—Four separate coils wound on ring to illustrate the action of a Gramme ring arma-ture. If the ring be rotated the electromotive forces induced in adjacent coils will beequal and tend to produce currents in opposite directions; hence, if the inner ends bejoined, the junctions would be at a…
