connected directly to the brushes as in fig. 196. 194 HAWKINS ELECTRICITY Ques. Describe the long shunt. Ans. In the long shunt, one end of the shunt winding isconnected to one of the brushes and the other end to the terminalconnecting the series winding with the external circuit as infig. 197.… … SHUNT SERIES ~> r MAIN CIRCUIT
