passes through it. The current 550 //.4irA/.V5 ELECTRICITY flows only in the portion of the wire marked A, between the plateE and the pulley B up to the point K where the connection isshown. When a cturent flows through the wire A, the springtakes up the slack, pulls A around B, and causes B to… … Fig. 638.—piagram showing principle and construction of the Whitney hot wire instruments.The action of instruments of this type depends on the heating of a wire by the passage ota current causing the wire to lengthen. This elongation is magnified by suitable mechan-ism and transmitted to the…
