Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 249
ues. How is a shunt motor started? Ans. In starting a shtint motor, no trouble is likely to occurin connecting the field coils to the circuit. Since the resistanceof the armature is very low, it is necessary on constant voltagecircuits to use a starting rheostat in series with the armatiu-e. The… … Figs. 739 and 740.—Multiple switch starters. Fig. 739, starter with no voltage release; fig.740, starter with no voltage release and circuit breaker. The multiple switch type ofstarter is designed to overcome the arcing on sliding contacts which, in the case of largemotors would be very severe. The…
Electrical engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
