Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 26
ppositeside of the system which gives a (juicker action. This regulation is auto-matic and the set takes care of unbalanced loads in either direction with-out adjustment. Balancing Coils.—Another method of balancing a three wiresystem which does away with any additional rotating machinesmakes use… … Fig. 801.—Diagram showing connections of balancing coil system. The dynamo used inthis system is provided with both commutator and collector rings. armature. These rings are much lighter than they would be fora converter as they carry only about 3^ of the dynamo load.These rings being light are…
Electrical engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
