having their windingsso arranged that they maybe connected in star for start-ing and in delta for running. Ques. Describe the oper-ation of a star delta switch^ Ans. In starting the motor,the drum lever is thrown in the 1.760 IIAWKIXS ELECTRICITY starting direction which connects the field windings… … ^^CJrcu/arD.SS C Sr, P/stc/7 Rod /f P* S. 2.470 to 2.474.—General Electric timelimit overload relay/ starting compen-sator. In case of overload, the relayarmature is raised and at the end of itstravel, opens the small switch at the topwhich in turn opens the circuit of thelow voltage release coil…
