ass tubeand the other to the brass rod. The other end of the cable is run through a bushing set inthepanei: I ----- or current transform •:•. Where it is desired to remove the plug and cable from the board, or to plug both ends cf the cable in di^erent recepta-cles, a plug instead of a bushing… … Fig. 2,206.—Westinghouse fused starting switch for squirrel cage motors. It is arranged forNational Electric Code fuses on one end only and has springs on the other end to openthe switch automatically if left closed at this end. The corresponding terminals at bothends of the switch are connected in…
