roiar^ with dynamo;3. Bridge. 2,226 HAWKINS ELECTRICITY Differential Duplex System.—This method employs arelay wound with two sets of coil, in each of which the currentflows in a different direction. Consequently, when two currentsof equal intensity are passed through the relay at the sametime,… … Fig. 3,074.—Diagram explaining the operation of a polarized relay. The relay consists essen-tially of a permanent magnet, electromagnet, and an armature arranged to vibrate betweena contact and a stop. The permanent magnet is of a curved shape as shown; at oneextremity is attached the…
