Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)

Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 317

An illustration from Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise, 1914, leaf 317
w 8 © 0 PUSHES 0 … Fig. 3,316.—Six drop annunciator circuit showing one burglar alarm switch. The six annun-ciator magnet windings are each connected on one side to a common wire connectingwith one bell binding post and the other ends of the magnet wires are each connected toseparate binding posts in the annunciator.…

Electrical engineering
