onnected, the field of the first is connected to the supplyand the armature to the field of the second motor; the armature of the ELECTRIC RAILWAYS 2,585 second motor is connected to the external resistance at start. As themotors speed up, the external resistance is cut out till armature of… … Pigs 3,638 and 3,639.—Westmghouse blow out coil. Fig. 3,638 view with side of box cut away;tig. d,od9, complete with pole piece. Each blow out coil consists of a number of turn ofcopper strap enclosed in an insulating box similar to the switch box. Each coil is secureto the base plate of the switch…
