Fig. 3,792.—Virtual focus in double concave lens. CASE I: Parallel incident rays. Fig. 3,793.—Virtual focus in double concave lens. CASE II: Divergent incident rays. In thiscase where the rays radiate from a point L on the axis, it is found by the same constructionthat a virtual focus is formed at… … Fig 3 794 —Effect of placing luminous source at the principal focus of a double convex lens.As the point of light comes near the lens, the convergence of the emergent rays decreasesand the conjugate^ focus L (fig. 3,788) becomes more distant., When the source of.light LcSmcides with the principal…
