Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 88
Figs. 3,918 to 3,921.— Hydraulic analogy of current. . Figs. 3,918and 3,919 show two tanks with discharge cocks of the samesize (equal resistances). Obviously the higher pressure in tankfig. 3,918 will cause a greater flow through its cock thanwill the low pressure in tank, fig. 3,919. The…
Electrical engineering
Internet Archive · Brigham Young University · Public Domain Mark 1.0. Free to use for anything.
