Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 28
een by attempting thewinding on the wooden core. A winding of this kind on thedrum fig. 258, would proceed as follows: A—1—7—BB—3—9—CC—5—11—D 240 HAWKINS ELECTRICITY In order now to continue winding in a regular way, the wirefrom segment d should pass to the rear of the armature alongspace 7, but… … Fig. 265.—Lap winding for bipolar machine, with uneven number of coils; in this case therear connectors may be made directly across a diameter as shown. Ques. How is a symmetrical winding obtained havingan even number of coils? Ans. The inductors, in passing from the front to the rearof the…
Electrical engineering
Internet Archive · Brigham Young University · Public Domain Mark 1.0. Free to use for anything.
