Heat energy and fuels: pyrometry, combustion, analysis of fuels and manufacture of charcoal, coke and fuel gases. Translated by Oskar Nagel (1908)
Jüptner von Jonstorff, Hanns, Freiherr, 1853- · New York McGraw · leaf 244
Fig. 68. — Coke Oven, System Smet (elevation). The horizontal ovens are constructed in different styles accord-ing to the path of the gas through the furnace. The most im-portant types are: Frangois-Rexroth coke oven (Fig. 66 cross-section. Fig. 67longitudinal section through chamber). 284 HEAT… … Fig. 69. — Coke Oven, System Sniet (plan).
Fuel · Heat
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
