Heat energy and fuels: pyrometry, combustion, analysis of fuels and manufacture of charcoal, coke and fuel gases. Translated by Oskar Nagel (1908)
Jüptner von Jonstorff, Hanns, Freiherr, 1853- · New York McGraw · leaf 245
Fig. 72. — Coke Oven, Francois (cross-section) COKING APPARATUS 235 The gases leave the chambers at the sides, pass through twohorizontal channels (in the side walls) then through two horizon-tal channels in the bottom into the flue. Smet coke oven (Fig. 08, front \iew and section; Fig. 69,section… … ry^VfW^A ~:r-h^ Fig. 7.3. — Coke Oven, Francois (longitvidinal section). nels near one of the side-walls and under the floor of the chamber.The gases leave the chamber at the highest point. Frangois coke oven (Fig. 72, cross-section; Fig. 73, longitutUnalsection). The gases of distillation leave at…
Fuel · Heat
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
