Heat energy and fuels: pyrometry, combustion, analysis of fuels and manufacture of charcoal, coke and fuel gases. Translated by Oskar Nagel (1908)

Jüptner von Jonstorff, Hanns, Freiherr, 1853- · New York McGraw · leaf 58

An illustration from Heat energy and fuels: pyrometry, combustion, analysis of fuels and manufacture of charcoal, coke and fuel gases. Translated by Oskar Nagel, 1908, leaf 58 — V … Figs. 4 and 5. — Spring Manometer. In order to render the instrument less fragile and to simpUfyits manipulation Wiborgh replaced the mercury-manometer bya spring-manometer (Figs. 4 and 5). The instrument rests in around metal box with heavy bottom (a), to which the por-celain pyrometer-tube {rV)…

Fuel · Heat

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
