Heat and light; an elementary text-book theoretical and practical for schools and colleges (1897)

Glazebrook, Richard, Sir, 1854-1935 · Cambridge : University Press · leaf 308

An illustration from Heat and light; an elementary text-book theoretical and practical for schools and colleges, 1897, leaf 308 — aced. ProduceSS backwards. It will be found that SS, and PP are parallelThe ray emerges parallel to its direction before incidence;there is no deviation; it is only displaced laterally. EXPERIMENT (12). To trace tJie path of a ray through aprism and to find the deviation. Repeat the last… … 72 LIGHT. [CH. IV that, it can emerge from the glass and is not totally reflectedat the face AC, it is turned as in the figure from the edge A. The ray is deviated through the angle TOS. Measure thiswith a protractor1, let it be D. Measure also i the angle ofthe prism, and <f> and \]/ the…

Heat · Light
