b. The pipes which conveythe highly concentrated solution into the generator at a, and thesolution of low concentration into the absorber at b, both passthrough the heat exchanger E. In the heat exchanger the solutionat a low temperature, going from the absorber to the generator,takes up heat from… … Fig. 56. sented by AB of Fig. 56. The change in pressure in going fromthe absorber through the generator is represented by the curveBC, and corresponds to the compression curve of the compressor.The line CD represents the condensation at constant pressure,the same as in Fig. 53. Finally, the curve…
