Hicks' Builders' guide, comprising an easy, practical system of estimating material and labor for carpenters, contractors and builders (1907)
Hicks, I. P. (Isaac Perry), b. 1856 · New York, David Williams company · leaf 27
Fig. 13.—Diagram for FindingArea of a Gable. … Fig. 14.—Finding Area of Gable when Roof is Less than Half Pitch. ings of a half pitch roof. With a roof of less pitch arectangle would be formed with A D for its lengthand D B for its breadlh, as shown in Fig. 14. In thisfigure the triangle A B C is equal in area to the rec- 26 THE BUILDERS GUIDE.…
Carpentry · Building
