High frequency apparatus, design, construction and practical application; a practical treatise for electrical engineers, electricans, physicians, students and experimenters (1920)
Curtis, Thomas Stanley · New York, Norman W. Henley publishing company · leaf 44
uction.—In each chapter of thisok, wherein a set of apparatus is described, the completespecifications for the construction of the transformer aregiven. The object of this discussion will, therefore, be tocover only briefly the essential principles of the construction.The transformer core in each… … Fig. 10.—Type E transformer with tongue of iron to increase magnetic leakage between windings iron and, if results count, it is much cheaper than stove-pipeiron. The construction of the core is simple. The siliconsteel can be bought in sheets or, preferably, in pieces cutto size and ready to…
Electric apparatus and appliances
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
