ghly impor-tant illustration for the schemeor skeleton of a Gothic vaultedconstruction and the connectionbetween the exterior buttressand flying buttress and theinterior arched ceiling. Ob-serve, as illustrated by the sideaisle, how the vaulting is al-ways protected by a timberroof. In this view… … Typical Gothic Capital, Esslingen. Notice here and in other Gothic GOTHIC ARCHITECTURE. 115 cathedrals the origin of the system of nave and aisles, and of the higher elevationof the nave, as shown in 44, 45, 46. For details of G-othic ornament in windows,gables, finials, crockets, and carved…
