see Fig. 254), the shuttles are thrown from side to side of the openings through the warp w. The advantage of this motion is that the shuttles are forced completely and surely through the shed, and are not liable to stop half way, as when driven by the driver used in the Dutch loom. Fig. 256 shows… … The bar loom shown in Figs. 250 and 251 is worked by hand, by means of the handle or bar B, which is connected to the exten- sions of the connecting rods working on the crankshaft G. This crankshaft works the tappet shaft T, which is named from the cir- cumstance that the various tappets or cams…
