sheet of paper a steel point(Fig. 35) with which it is furnished. This lever is depressed bymeans of the electro-magnet, which attracts the armature fixed tothe levers; every time that the current passes in the wire ofthe electro-magnet, the armature draws the lever to which it isfixed, and thus… … Fig. 35. a helical spring attached to the under side of the lever compelsit, by its elasticity, to separate itself from the electro-magnet,when the current ceases to act, \vhich*causes the point no longerto press. The other part of the apparatus is intended to cause a
