Brechner, Claude H., 1887- [from old catalog] · Boston, New York [etc.] Allyn and Bacon · leaf 127
e of the lens as theobject, (2) larger than the object, (3) erect, and (4) virtual. 139. Image through a Diverging Lens. — There werefive distinctive positions for the object in the case of theconverging lens, but for the diverging lens there is only one.The image may be constructed in a similar… … Object Figure 102.— Construction of Image through a Diverging Lens. through the principal focus. These produced rays meetthe rays coming from the same points and form an imagewhich is (1) between F and the lens, (2) smaller than theobject, (3) erect, and (4) virtual. No matter where the object is,…
Physics
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
