the boiler, pipes are led off to the radiators in thedifferent rooms. Returning from the other end of theradiators are pipes to bring the water back to the bottom Figure 36. — Diagram of the HeatingSystem of a Hot-water Tank. 52 HEAT TRANSFERENCE of the boiler. The pipes going up to the radiators… … Figure 37. — A Kerosene Heater Used in Connection with thiHot-water Tank. HOT-WATER HEATING SYSTEM 53 Before the furnace is started, water is let in from the citymain until the whole system is full and water rises into theexpansion tank. Then the stop-cock is closed, so that nomore water can get in…
