Ferris, Richard. [from old catalog] · New York, T. Nelson and sons · leaf 120
line with the rear edge of the main plane, andabove it. The forward part of the body is enclosedwith fabric. The machine is mounted on three wheels attached FLYING MACHINES: THE MONOPLANE. 119 to the body: two at the front, with a powerful springsuspension and pivoted like a caster, and the… … Diagram of Bleriot No. XL, from the rear. A, A, main plane; B, tail; C,body; D, D, wing tips of tail; E, rudder; H, propeller; M, motor; 0, axisof wing tips; R, radiator; a, a, b, b, spars of wings; h, h, guy wires;p, k, truss. controls are actuated by a single lever and a drumto which the several…
Aeronautics
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
