Hydraulic engineering; a practical treatise on the principles of water pressure and flow and their application to the development of water power, including the calculation, design and construction of water wheels, turbines, and other details of hydraulic power plants (1909)
American School (Chicago, Ill.), Black, Adolph, Turneaure, Frederick Eugene, 1866- · Chicago American School of Correspondence · leaf 295
)lice-plates with three rows of rivets oneaeh side. A vertical recess about 15 feet scjuare and 50 feet high was exitout of the soHd rock at the base of the cHff, and in it was set the bottom … Fig- IS?. Oeueval Dimensions f)f Penstock of the Xiagani Falls Hydraulic- Power& Manufacturing Conipanj-. of the vertical portion of the penstock. At the lower elbow, the pen-stock increases to 13 feet in diameter, and then decreases, as it passesthe turbines, to a diameter of 7 feet at the…
