I.C.S. reference library : a series of textbooks prepared for the students of the International Correspondence Schools and containing in permanent form the instruction papers examination questions, and keys used in their various courses (1904)

International Correspondence Schools · Scranton : International Textbook Co. · leaf 330

An illustration from I.C.S. reference library : a series of textbooks prepared for the students of the International Correspondence Schools and containing in permanent form the instruction papers examination questions, and keys used in their various courses, 1904, leaf 330 — both sidesof the piston is equal.The upper part ofthe plunger, however,has an equal pressureon both its sides onlywhen it is down, asin Fig. 21 {b). Whenit is drawn up, theair in the space Dexpands and a partialvacuum is formed.The valve gear nextreleases the plunger,and as the atmos-pheric… … 44 MECHANICS OF FLUIDS. 6 thus gradually brought to rest. The valve C serves toregulate the amount of compression and at the same timeadmits air during the up stroke of the plunger. THE SIPHOX. 63. Theory of tlie Siphon.—The action of the siphon illustrates the effect of atmospheric pressure. It is…
