Fig. 43. are arranged in the form of four dials. This pattern is knownas the dial pattern, and is widely used in making resistancemeasurements. Example.—The diagram in Fig. 44 represents a particular type ofWheatstones bridge to which a battery and galvanometer are properlyconnected for measuring… … Fig. 44. g, t\ k, m, q, and t are drawn, and when both the contact keys ^and ICare pressed, the galvanometer shows no deflection. Determine theresistance of x. Solution.—From the connections of the galvanometer and batterycircuits, it will be seen that the resistance coils in line G H representthe…
