fi?. 98. *54 ILLISTRATED ARCHITECTURAL, post; the capital of impost is obtained by dividing fi h into seven or eightequal parts, and giving one of these from m to n ; the width of archivolt sois equal to one-ninth part of // h; the width of keystone at efis equal to0 s. By drawing lines to e and…
