fig, 121, is the front elevation of a bay-window onground-floor, with projecting or oriel window over it on bedroom-floor, inthe Elizabethan or Jacobin style, drawn to a scale of one-eighth inch to afoot. The side elevation of this drawing is shown in Example 120, fig. 122, same scale as above.…
