Burn, Robert Scott · London : Ingram, Cooke, and Co. · leaf 88
fig. 48. The annexed figure (48), representing the jetty at Birkenhead as seenfrom the river, with the inclined ascent up to it, demonstrates the mode of … fig. 49. finding the vanishing-point of the inclined plane, the points d and e beingfirst obtained by the perspective lines of the jetty. Produce d e, intersect- 80 ILLUSTRATED LONDON DRAWING-BOOK. ing a b at V1, which will be the vanishing-point of the incline ; while V2on the horizontal line,…
Drawing · Wood-engraving
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
