Illustrations of the theory and practice of ventilation : with remarks on warming, exclusive lighting, and the communication of sound (1844)

Reid, D. B. (David Boswell), 1805-1863 · London : Longman, Brown, Green, & Longmans · leaf 404

An illustration from Illustrations of the theory and practice of ventilation : with remarks on warming, exclusive lighting, and the communication of sound, 1844, leaf 404
partof these cabins, the deck above, and the hold, facilities are notwanting for the application of power. Continuing with Fig. 276, w indicates the well; A the mainhatch; B the sail room; C C cable tiers ; E the fore hatch;F boatswain ; Gr marine officer ; H slop-room; I scuttle to themagazine; K… … 380 FACILITIES FOR VENTILATING LARGE SHIPS. the movement of a circling series of currents that may be tracedoccasionally between them, very slight circumstances varyingthe inclination from A to E or E to A. 799. Fig. 277 points out the vacant spaces that are to be Fig. 277. s II B iilli > =Sy…

Ventilation · Heating · Lighting · Architectural acoustics
