An improved and enlarged edition of Biddle's young carpenter's assistant : being a complete system of architecture for carpenters, joiners, and workmen in general, adapted to the style of building in the United States ; revised and corrected, with several additional articles, and forty-eight new designs, chiefly of full size, working drawings of modern finish, in detail ; particularly adapted for country use (1833)

Biddle, Owen, Haviland, John, 1792-1852 · Philadelphia : M'Carty & Davis, 171 Market Street · leaf 174

An illustration from An improved and enlarged edition of Biddle's young carpenter's assistant : being a complete system of architecture for carpenters, joiners, and workmen in general, adapted to the style of building in the United States ; revised and corrected, with several additional articles, and forty-eight new designs, chiefly of full size, working drawings of modern finish, in detail ; particularly adapted for country use, 1833, leaf 174
laced them by others. The superstructure of this Steeple is composed of three distinct well-proportionedparts of Architecture; the first story, with its small Pediments and Attics, formingone ; the octagonal part, with its ogee-formed Dome, being the second ; and the spireand its pedest^al, the… … PLATK 03.

Architecture · Architectural drawing

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
