Industrial drawing and geometry; an introduction to various branches of technical drawing (1911)
Spooner, Henry John, 1856- · London, New York [etc.] Longmans, Green, and co. · leaf 111
attern for tiles, etc. 175. Hexagons in a Rectangle.—Figs. 281 and 282 show two steps in drawing a pattern formed by hexagons, and based on 92 INDUSTRIAL DRAWING AND GEOMETRY equilateral triangles, as in Fig. 256. These should now speak for themselves. Two variations of these are shown in Figs. 283…
Mechanical drawing · Geometrical drawing
