Industrial drawing and geometry; an introduction to various branches of technical drawing (1911)
Spooner, Henry John, 1856- · London, New York [etc.] Longmans, Green, and co. · leaf 87
By Paper Trammel.—Let AB and CD, Fig. 213, be the two given axes at right angles to each other at their centres O. Then if on a strip of paper, or the straight-edge of a card, the semi-axes be markedfrom any point, the strip can be used to find points in the curve in the following way. The strip…
Mechanical drawing · Geometrical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
