Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 194
eans of a pedal, which, when depressed, causescurrent to flow from the battery to the motor for cranking the engine. The plate which carriesthe terminals of the switch also supports the metal band or strap termed the switch shunt.The cable terminals are secured to the switch by means of a lock… … Fig. 16. Bosch Starter and Lighting Systems. 192 INFORMATION be no serious consequence, for the pinion on the motor shaft will not engage with the flywheeland the armature will rotate freely. It then becomes necessary to allow the pedal to resumeits non-operating position so the starter can be…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
