h, as the series field circuit, whichdoes most of the work when the starter-generator is used as a motor, has not been broken. STORAGE BATTERY The battery is of the 6-cell, 12-volt type. It is located under the drivers seat, at theleft side. Besides the two wires leading from it to the starting… … v k 4/S . *N 10 If 4 02 be There are two head lights, a dash light, and a tail light. The lamp sizes are. Head lights 15 candle power—14 volts Tail light 2 candle power—16 volts Dash light 2 candle power—16 volts Both headhghts are connected to one terminal of the lighting switch by separate…
