Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 257
of the three oilers of the magneto should be given afew drops of oil about every thousand miles. The cam is lubricated by means ofa felt wick. This wick should be inspected often enough to keep it from runningdry. It should be well saturated with oil, by means of a squirt can, whenever itappears to… … Type RD—Four-Cylinder Wiring Plan Fig. 19. MAGNETOS 255 position, and the platinum points must just be separating. The high tension cablefrom this cylinder, which is on exact dead firing center, should then be connectedto the distributor terminal, corresponding to which the distributor segment is…
