Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 296
Figure 41, excepting that the volt-meter is connected directly across the headlights. There should not be a drop ofover one-half volt over that of a reading taken at the terminals of the battery. Ifvoltage is all right up to this point, and the light burns exceptionally bright, thevoltage of the… … AMMETER O % 0 FIG. 43 Figure 43. This shows the primary winding of an induction coil as used forignition purposes connected in series with an ammeter and a six-volt storage bat-tery. This is a practical test for open or partially short-circuited primary winding. If ammeter does not show a reading,…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
