Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 98
ees to set exhaust valve justclosing. 112. Fig. 4 shows the flywheel markings for a six-cylinder engine. The cranks in asix-cylinder engine are set in pairs, each pair being 120 degrees from the others. That is,pistons 1 and 6 are in line, so also are 2 and 5 and 3 and 4. The timing for the… … Fig. 4 113. Firing Order. The cylinders of a gasoline engine are generally numbered fromthe front, the one next to the radiator being No. 1. Now it would not be practical to fire thecylinders in succession 1, 2, 3, 4, etc., on account of the rocking motion which would result. 96 INFORMATION For…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
