The internal combustion engine; a text-book for the use of students and engineers (1915)
Wimperis, Harry Egerton, 1876- · New York, D. Van Nostrand company · leaf 145
p, v sheet fastened round the drum seen on the right which ismade to oscillate to and fro by the cord shown on the extremeright of the diagram being attached to a moving link which hasa motion similar to that of the piston, but less in amount.The pencil therefore traces out the closed curve known…
Internal combustion engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
